Restoring a MySQL Database to a Point in Time

Candy3 min read
Restoring a MySQL Database to a Point in Time

Bytebase is an open source database DevOps tool, it's the GitLab for managing databases throughout the software development lifecycle (SDLC). It offers a web-based workspace for Developers and DBAs to collaborate and execute database changes safely and efficiently.

As an application developer, what would you do if you encountered these scenarios in your daily work?

  • Someone accidentally drops a table or deletes a bunch of customer data.
  • Team releases a bad version with database changes.

You want a time travel.

For MySQL, this means you would look for the valid backup and the relevant binlog files to recover to a point in the past before the incident occurred. This is a complicated process that requires an experienced DBA to operate. Today, we are introducing Point-in-Time Recovery (PITR) Beta in Bytebase, which enables users to perform this error-prone operation with just a few clicks.

How MySQL PITR works in Bytebase?

  1. Find the most recent backup before the specified recovery point in time.
  2. Restore the backup to a temporary database.
  3. Replay the binlog files to that temporary database up to the specified point in time.
  4. Swap the temporary database with the targeting database.

The last step means Bytebase is doing an in-place database recovery and does not require any application code change.

How to Restore a Database to a Point in Time?

Let’s say there is a MySQL database db_pitr_example that has two tables pitr_one and pitr_two. original

Suddenly, the application goes down since someone accidentally deletes the table pitr_two. Then, the DBA or the on-call developer needs to restore that deleted table. del

The following steps demonstrate how to restore the database db_pitr_example with PITR.

Step1. Click Restore to point in time under Backup and restore. pitr-step1

Step2. Choose a point in time to restore the database, and click Confirm. pitr-step2

Step3. Click Approve to execute the first task, or reassign it to someone else to review the task first. pitr-step3

After the first task is completed, click Approve again to execute the second task. pitr-step4

Now, the point-in-time recovery for the database is done. The result says that the database db_pitr_example has performed point-in-time recovery successfully. result

Let’s verify tables in the database db_pitr_example. The deleted table pitr_two is back again. verify

Learn more

We just showed you how Bytebase performs a point-in-time recovery. It’s an in-place recovery, which means it does not require extra work to change the application code after the recovery. To learn more about Point-in-Time Recovery in Bytebase, see our documentation.

Thank you for reading this post. If you have any comments or questions, don’t hesitate to let us know.
